Network Technology GSM / CDMA / HSPA / EVDO / LTE / 5G
Launch Announced 2025, July 09
Status Coming soon. Exp. release 2025, July 25
Body Dimensions Unfolded: 166.7 x 75.2 x 6.5 mm
Folded: 85.5 x 75.2 x 13.7 mm
Weight 188 g (6.63 oz)
Build Plastic front (unfolded), glass back (Gorilla Glass Victus 2), aluminum frame
SIM Nano-SIM + eSIM + eSIM (max 2 at a time)
Nano-SIM + multiple eSIM (max 2 at a time)
IP48 dust and water resistant (dust > 1mm; immersible up to 1.5m for 30 min)
Armor aluminum frame
Display Type Foldable Dynamic LTPO AMOLED 2X, 120Hz, HDR10+, 2600 nits (peak)
Size 6.9 inches, 111.2 cm2 (~88.7% screen-to-body ratio)
Resolution 1080 x 2520 pixels, 21:9 ratio (~397 ppi density)
Cover display:
Super AMOLED, 120Hz, 2600 nits (peak), 4.1 inches, 948 x 1048 pixels (Gorilla Glass Victus 2)
Platform OS Android 16, up to 7 major Android upgrades, One UI 8
Chipset Exynos 2500 (3 nm)
CPU 10-core (1x3.3GHz Cortex-X5 & 2x2.74GHz Cortex-A725 & 5x2.36GHz Cortex-A725 & 2x1.8GHz Cortex-A520)
GPU Xclipse 950
Memory Card slot No
Internal 256GB 12GB RAM, 512GB 12GB RAM
UFS 4.0
Main Camera Dual 50 MP, f/1.8, 23mm (wide), 1/1.57", 1.0µm, dual pixel PDAF, OIS
12 MP, f/2.2, 13mm, 123˚ (ultrawide), 1/3.2", 1.12µm
Features LED flash, HDR, panorama
Video 4K@30/60fps, 1080p@60/120/240fps, 720p@960fps, HDR10+
Selfie camera Single 10 MP, f/2.2, 23mm (wide), 1/3.0", 1.22µm
Features HDR
Video 4K@30/60fps
Sound Loudspeaker Yes, with stereo speakers
3.5mm jack No
32-bit/384kHz audio
Comms WLAN Wi-Fi 802.11 a/b/g/n/ac/6e/7, tri-band, Wi-Fi Direct
Bluetooth 5.4, A2DP, LE
Positioning GPS, GALILEO, GLONASS, BDS, QZSS
NFC Yes
Radio No
USB USB Type-C 3.2, OTG
Features Sensors Fingerprint (side-mounted), accelerometer, gyro, proximity, compass, barometer
Circle to Search
Samsung DeX (desktop experience support)
Battery Type 4300 mAh
Charging 25W wired, QC2.0, 50% in 30 min
15W wireless
4.5W reverse wireless
Misc Colors Blue Shadow, Jet Black, Coral Red, Mint
Models SM-F766B, SM-F766B/DS, SM-F766U, SM-F766U1
SAR 0.86 W/kg (head) 1.14 W/kg (body)
SAR EU 0.69 W/kg (head) 1.22 W/kg (body)
